Catalogue
KST Catalogue Page
Tsurumi Catalogue 2024 - Page 42KST-05
| Item Code | Model | Outlet (mm) | kW | Volt (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 15-10-1065 | KST-05 | 50 | 0.4 | 400 | 260 | 10 | 5 | 156 | 230 | 375 | 14.5 |
KST-08
| Item Code | Model | Outlet (mm) | kW | Volt (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 15-10-1061 | KST-08 | 50 | 0.75 | 400 | 380 | 13 | 6 | 180 | 290 | 425 | 21.2 |
KST-20
| Item Code | Model | Outlet (mm) | kW | Volt (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 15-10-1020 | KST-20 | 80 | 1.5 | 400 | 600 | 16 | 9 | 182 | 278 | 475 | 31 |
KST-30
| Item Code | Model | Outlet (mm) | kW | Volt | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) |
| 15-10-1010 | KST-30 | 80 | 2.2 | 400 | 800 | 18 | 11 | 255 | 465 | 535 |
KST-50
| Item Code | Model | Outlet (BSPM) | kW | Volt | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) |
| 15-10-1011 | KST-50 | 4" | 3.7 | 400 | 1000 | 21 | 11 | 255 | 465 | 565 |
KST-75
| Item Code | Model | Outlet (BSPM) | kW | Volt | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) |
| 15-10-1103 | KST-75 | 4" | 5.5 | 400 | 1300 | 23 | 11 | 330 | 570 | 700 |
KST-100
| Item Code | Model | Outlet (BSPM) | kW | Volt | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) |
| 15-10-1079 | KST-100 | 6" | 7.5 | 400 | 1600 | 25 | 11 | 330 | 570 | 720 |
