Tsurumi Catalogue 2024 - Page 6450B2.75
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1121 | 50B2.75 | 2" BSPF | 0.75 | 400 | 440 | 12 | 20 | 250 | 405 | 436 | 25 |
80B21.5
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1117 | 80B21.5 | 3" BSPF | 1.5 | 400 | 1000 | 17 | 40 | 250 | 446 | 536 | 36 |
100B42.2
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1230 | 100B42.2 | 4" BSPF | 2.2 | 400 | 1500 | 16 | 45 | 331 | 569 | 616 | 70 |
100B43.7
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1211 | 100B43.7 | 4" BSPF | 3.7 | 400 | 2000 | 16 | 53 | 339 | 575 | 690 | 86 |
100B43.7H
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1090 | 100B43.7H | 4" BSPF | 3.7 | 400 | 1150 | 20 | 35 | 331 | 569 | 666 | 84 |
100B45.5
| Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 10-10-1036 | 100B45.5 | 4" BSPF | 5.5 | 400 | 2050 | 26 | 40 | 400 | 687 | 824 | 147 |
100B47.5
Item Code | Model | Outlet (mm) | kW | Volts (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
10-10-1025 | 100B47.5 | 4" BSPF | 7.5 | 400 | 2260 | 30 | 40 | 400 | 687 | 814 | 169 |
50B2.4
| item code | model | bore (mm) | kW | volt | flow (l/min) | head (mtrs) | free passage (mm) | w x l x h (mm) *inc elbow | dry weight (kgs) |
| 10-10-1285 | 50B2.4 | 50 | 0.4 | 400 | 265 | 9 | 19 | 224x347x443 | 23 |
50B2.75H
| item code | model | bore (mm) | kW | volt | flow (l/min) | head (mtrs) | free passage (mm) | w x l x h (mm) *inc elbow | dry weight (kgs) |
| 10-10-1295 | 50B2.75H | 50 | 0.75 | 400 | 365 | 15.5 | 20 | 250x405x415 | 25 |
150B43.7
| item code | model | bore (mm) | kW | volt | flow (l/min) | head (mtrs) | free passage (mm) | w x l x h (mm) *inc elbow | dry weight (kgs) |
| 10-10-1303 | 150B43.7 | 150 | 3.7 | 400 | 4000 | 7 | 53 | 486x871x875 | 145 |
150B47.5L
| item code | model | bore (mm) | kW | volt | flow (l/min) | head (mtrs) | free passage (mm) | w x l x h (mm) *inc elbow | dry weight (kgs) |
| 10-10-1308 | 150B47.5L | 150 | 7.5 | 400 | 5000 | 14 | 60 | 486x871x1085 | 200 |
150B415
| item code | model | bore (mm) | kW | volt | flow (l/min) | head (mtrs) | free passage (mm) | w x l x h (mm) *inc elbow | dry weight (kgs) |
| 10-10-1313 | 150B415 | 150 | 15 | 400 | 4500 | 28 | 75 | 490x895x1168 | 270 |
